CONVENTIONAL FIRE CONTROL PANELS

PRODUCT OVERVIEW

The Supreme CP range of conventional fire control panels with optional built in communicator are available with 2, 4 or 8 initiating circuits which may be extensively configured via a simple front panel operated programming method. The low standby power requirements and cost effective small batteries allow the panel to be mounted in a small discrete enclosure which is available in standard red or optionally in an attractive gray color.

Conventional Fire Control Panels

STANDARD FEATURES

1)UL864 approved

2)Two, four or eight initiating circuits

3)Initiating circuits individually configurable as Fire, or Supervisory

4)Two 2.SA Notification Appliance Circuits

5)4.0 Amps total NAC power available

6)Selectable NAC sync protocols

7)5 Amp power supply

8)Resettable Aux power output rated at 0.3A

9)Aux power configurable to power off on Fire condition

10)Fire, Trouble and Supervisory relays

11)Many advanced configuration options

12)24-hours standby with 7 Ah batteries

13)Optional DACT (SIA or Contact ID allowing user-definable reporting codes)

More Avengere Products.

Technical Specifications:

Size: 14.5”W x 12.2”H x 4.25”D

Construction: 18AWG mild steel

Finish: Epoxy powder coated

Color : Red (optional gray).

Supply Voltage: 115V AC or 230V AC

Mains Supply fuse: 5 Amp 250V 20mm

Power supply DC rating: 24V 5 Amps

Operating temperature: 23°F to 122°F

Operating humidity: <95% (non-condensing)
