Description:

The next generation of the industry’s best-selling dental mill has kept everything users love, and then made it even better. Reliable, precise and affordable, the DWX-52D 5-Axis Dental Milling Machine now offers better disc handling, more material capabilities, improved tool management and other enhanced features, to deliver even more efficiency.

New Medical Electronic, Dental Device and ophthalmic device for hospital

WWW . LATIEF-ALHAKIM . COM, We specialize in exporting brand New Medical Electronic, Dental Equipment, Ultrasound Machine and Ophthalmic Device to any country of the world. We supply best of quality Medical Electronic, Dental Equipment, Ultrasound Machine and Ophthalmic Device including major models from best brand makers.Currently we offer products from: Aescalup Meditec, Argus optic, good, BKG, Canon, Clement clarke, Coherent, Ellex, Haag dispute, Heine, Humphrey, Hoya, Huvitz, iCare, Kowa, Magnon, Medmont, Melag, Möller-Wedel, Neitz, Nidek, Nikon, Oculus, Reichert, Shin Nippon, Takagi, Tomey, Topcon, Zeiss and many mores. Please visit our site or contact us to check our product availability. Worldwide Shipping Service Available! For more information regarding the product, you can visit our official website. WWW . LATIEF - ALHAKIM . COM

Specifications

Cuttable materialZirconia, Wax, PMMA, Composite resin, PEEK, Gypsum, Glass fiber reinforced resin, Chrome Cobalt sintered metal

Loadable workpiece shapeExternal Diameter98.5 mm

Max Height60 mm

Step10 mm

Pin Type Diameter6 mm

Loadable workpiece weightUp to 850 g

Number of adapters housed6

Operating speedXYZ axis:6 to 1,800 mm/min. (0.24 to 70.9 in./min.)

Spindle motorBrushless DC Motor

Spindle speed6,000 to 30,000 rpm

Rotary axis travel angleA axis±360°

B axis±30°

Number of burs housed15

Attachable burShank diameter4 mm

Length40-55 mm

Compatible compressed air0.05/0.2 MPa (Automatic switch)

InterfaceUSB

Control command setRML-1, NC code

Power requirementsAC 100 V to 240 V ±10%, 50/60 Hz, 2.0 A (overvoltage category II, IEC60664-1)

Power consumptionApproximately 200 W

Operating noiseDuring operation70 dB(A) or less (when not cutting)

During standby45 dB(A) or less

External dimensionsWidth 19.5 in (495 mm)

Depth26.0 in (660 mm)

Height23.6 in (600 mm)

Weight 147.7 lbs. (67 kg)

Installation environmentAltitude Up to 6,562 ft. (2,000m)

Temperature41 to 104 °F

5 to 40°C

Humidity 35 to 80% (no condensation)

Ambient pollution degree 2 (as specified by IEC 60664-1)

Short-term temporary overvoltage 1,440 V

Long-term temporary overvoltage 490 V

Included items Power cord, power plug adapter, USB cable, manuals, Roland DG software package CD, detection pin, automatic correction jig, pin-type material adapter, hexagonal driver, spanner, milling bur holders, milling bur positioner, dust collection hoses, dust collection hose adapter, regulator, cleaning tool, option adapter labels, material adapters, material adapter rack

Operating system Windows® 7/8/8.1/10 (32 or 64 bit)

USB cable Use the included USB cable

Specifications

Cuttable materialZirconia, Wax, PMMA, Composite resin, PEEK, Gypsum, Glass fiber reinforced resin, Chrome Cobalt sintered metal

Loadable workpiece shapeExternal Diameter98.5 mm

Max Height60 mm

Step10 mm

Pin Type Diameter6 mm

Loadable workpiece weightUp to 850 g

Number of adapters housed6

Operating speedXYZ axis:6 to 1,800 mm/min. (0.24 to 70.9 in./min.)

Spindle motorBrushless DC Motor

Spindle speed6,000 to 30,000 rpm

Rotary axis travel angleA axis±360°

B axis±30°

Number of burs housed15

Attachable bur Shank diameter 4 mm

Length40-55 mm

Compatible compressed air0.05/0.2 MPa (Automatic switch)

InterfaceUSB

Control command setRML-1, NC code

Power requirementsAC 100 V to 240 V ±10%, 50/60 Hz, 2.0 A (overvoltage category II, IEC60664-1)

Power consumption: Approximately 200 W

Operating noiseDuring operation70 dB(A) or less (when not cutting)

During standby45 dB(A) or less

External dimensions: Width 19.5 in (495 mm)

Depth26.0 in (660 mm)

Height23.6 in (600 mm)

Weight 147.7 lbs. (67 kg)

Installation environmentAltitude Up to 6,562 ft. (2,000m)

Temperature41 to 104 °F

5 to 40°C

Humidity 35 to 80% (no condensation)

Ambient pollution degree 2 (as specified by IEC 60664-1)

Short-term temporary overvoltage 1,440 V

Long-term temporary overvoltage 490 V

Included items Power cord, power plug adapter, USB cable, manuals, Roland DG software package CD, detection pin, automatic correction jig, pin-type material adapter, hexagonal driver, spanner, milling bur holders, milling bur positioner, dust collection hoses, dust collection hose adapter, regulator, cleaning tool, option adapter labels, material adapters, material adapter rack

Operating system Windows® 7/8/8.1/10 (32 or 64 bit)

USB cable Use the included USB cable
